Alaska Marine Highway System
107 m Vehicle/Passenger Ferry
SOLAS Compliance and Machinery Upgrades
MV Taku
The MV Taku was retrofitted with new CP
Propellers. The existing PMC control system
was upgraded to a digital propulsion control system in accordance with ABS and USCG requirements.
Machinery Specifications
- 2 x MaK 8M453C main engines 2940 kW @ 600 rpm
(existing)
- 2 x reduction gearboxes with pneumatically actuated
clutches (existing)
- 2 x Ulstein E85/4-FOD G95 CP Propellers (new)
PMC Supplied Equipment
- Type 8550-3200
MPC-CP Marine Propulsion Control System for vessels with controllable
pitch propellers
- Electronic Speed Control with Electro-Pneumatic
Interface
- Electronic Pitch Control / Automatic Load Control
- Type 5400-1100
PCH Electric Shaft Control Heads with Type
5500-5000 DCH Remote Display
- Type 8421 UDC
Universal Display and Control Panels
- Electro-Pneumatic Clutch Control Panels with Soft Engage
- Type 8001 Alarm
Panels
- Type 8118 Digital
Tachometers
- Drop-in Propulsion Control and Instrumentation Plates
